DZ-10GW-1B

Image is for reference, please contact us to get the real picture

Manufacturer Part

DZ-10GW-1B

Manufacturer
Omron Automation & Safety Services
Description
SWITCH SNAP ACTION DPDT 10A 125V
Category
Switches
Family
Snap Action, Limit Switches
Series
-
InStock
10
Datasheets Online
DZ-10GW-1B PDF
Inquiry
  • Series:DZ
  • Package:Bulk
  • Part Status:Active
  • Circuit:DPDT
  • Switch Function:On-Mom
  • Current Rating (Amps):10A (AC/DC)
  • Voltage Rating - AC:125 V
  • Voltage Rating - DC:30 V
  • Actuator Type:Lever, Straight
  • Mounting Type:Chassis Mount
  • Termination Style:Screw Terminal
  • Ingress Protection:IP00
  • Features:-
  • Operating Force:170gf
  • Release Force:28gf
  • Pretravel:-
  • Differential Travel:0.156" (4.0mm)
  • Overtravel:0.062" (1.6mm)
  • Operating Temperature:-25°C ~ 80°C
Shipping Delivery period For in-stock parts, orders are estimated to ship out in 3 days.
We ships orders once a day at about 5pm except Sunday.
Once shipped, estimated delivery time depends on the below couriers you chose.
DHL Express, 3-7 business days
DHL eCommerce,12-22 business days
FedEx International Priority, 3-7 business days
EMS, 10-15 business days
Registered Air Mail, 15-30 business days
Shipping rates Shipping rates for your order can be found in the shopping cart.
Shipping option We provide DHL, FedEx, UPS, EMS, SF Express, and Registered Air Mail international shipping.
Shipping tracking We will notify you by email with tracking number once order is shipped.
You can also find the tracking number in order history.
Returning / Warranty Returning Returns are normally accepted when completed within 30 days from date of shipment,please contact customer service for a return authorization.
Parts should be unused and in original packaging.
Customer has to take charge for the shipping.
Warranty All purchases come with a 30-day money-back return policy, plus a 90-day warranty against any manufacturing defects.
This warranty shall not apply to any item where defects have been caused by improper customer assembly, failure by customer to follow instructions, product modification, negligent or improper operation
